Insertion loss

<0.3dB

≤0.2dB

<0.3dB

<0.3dB

Return loss

≥50dB

≥50dB

≥65dB

≥35dB

Repeatability

≤0.1

≤0.1

≤0.1

≤0.1

Durability

<0.1dB typical change,1000 mating

Interchangeability

≤0.2dB

Vibration

≤0.2dB

Operating Temperature

- 20°C ~ + 70°C

Storage Temperature

- 40°C ~ + 80°C

Cable Diameter

3.0mm, 2.0mm, 0.9mm

0

1

2

3

2

4

5

6

7

0

Brand name

1

Connector#1 LC,SC,FC,ST,E2000,DIN,D4,MU,MTRJ,etc.

2

Lapping Way PC&APC (For MTRJ, F=Female, M=Male)

3

Connector#2 LC,SC,FC,ST,E2000,DIN,D4,MU,MTRJ,Pigtail,etc.

4

Cable Type SM(9/125μm) ,MM(50/125μm & 62.5/125μm)

5

Fiber Number SX(Simplex) or DX(Duplex)

6

Cable Diameter 2.0=Ø2.0mm, 3.0=Ø3.0mm, 0.9=Ø0.9mm, etc.

  7

Cable Length 3m(Length in meter)
