lStorage and forwarding capabilities to support rate adaptation and protocol translation;

lAdaptive connection 10M、100M and 1000M network and the network port supports full-duplex/ half-duplex adaptation and traffic control;

lAutomatic detection and correction of incorrect poles on each port of a twisted pair;

lData transfer rate (line speed) is 14,880 frames per second (10M);

lData transfer rate (line speed) is 14,8800 frames per second (100M);

lData transfer rate (line speed) is 14,88000 frames per second (1000M);

lThe amount of power ≤ 5W;

lSupport 12K effective MAC address table; Supports MAC address learning and aging automatically;

l8 MB packet buffer;

lWith broadcast storm protection;

lSupport physical isolation and logical isolation. Through a key to achieve switching function and physical isolation function selection, on-site debugging convenient, stable and reliable (see product reference diagram red button)

size：199*88*25mm
