lStorage and forwarding capabilities to support rate adaptation and protocol translation;

lAdaptive connection 10M and 100M network and the network port supports full-duplex/ half-duplex adaptation and traffic control;

lAutomatic detection and correction of incorrect poles on each port of a twisted pair;

lData transfer rate (line speed) is 14,880 frames per second (10M);

lData transfer rate (line speed) is 14,8800 frames per second (100M);

lThe amount of power ≤ 5W;

lSupport 12K effective MAC address table; Supports MAC address learning and aging automatically;

l8 MB packet buffer;

lWith broadcast storm protection;

lComply with IEEE802.3, IEEE802.3u standard;

lFlow control methods: full duplex using IEEE802.3x standards, half-duplex using Back-pressure technology;

l4*10/100M adaptive RJ45 port, support port auto-flip (AutoMDI / MDIX);

lProvide 1*100M optical port to meet the requirements of long-distance transmission;

lSupport 4 groups of Port VLAN and MTU VLAN functions;

lProvide port bandwidth control function, the minimum granularity is 128kbps;

lSupport IEEE802.1p priority protocol mode, secondary static port priority mode and ToS priority mode, support for broadcast storm control;

lProvide fixed IP address settings;

lSupport switching system software upgrades, configuration file saving and recovery;

lExternal 5V1A switching power supply;

lSupport physical isolation and logical isolation

95*70*25mm
