CPU

MT7628DAN+MT7613BEN

Flash

8M

DDR2

64M

2.4G Working frequency

2.4GHz – 2.484GHz

2.4G WIFI Transfer Protocol

802.11 b / g / n

5G Working frequency

5.150GHz～5.850GHz

5G WIFI Transfer Protocol

802.11 a / n / ac

Built-in antenna 2 .4G

Omnidirectional antenna 2pcs, each gain: 2dBi

Built-in antenna 5G

Omnidirectional antenna 2pcs, each gain: 2dBi

SSID hide

Support

Top speed

1200Mbps

Maximum support for wireless access

100+

Maximum transmit power

<21dBm

Interface (WAN)

1 10/100M adaptive WAN port, support 48V POE power supply

Interface （LAN）

Interface (LAN) 1 10/100M adaptive LAN port

POE

48V 0.5A

Reset

reset key (short press once to turn off the light, short press twice in a row to turn off the light and WIFI, long press for 10 seconds to restore the factory default configuration)

Status Indicator

system lights

Maximum power consumption

<8W

ESD test- I

air discharge:±4KV

Surge test- I

common mode：±2KV

Product size

87mm*86mm*35.8mm

working environment

Normal operating temperature: -20°C to 55°C; Extreme operating temperature -30°C to 70°C; Storage temperature: -40°C to 70°C; Humidity: 5%～95% (non-condensing)
